S68R38減速機詳細信息
S68R38減速機
訂購熱線：13360667204
S68R38減速機電機功率：S68R38Y0.12KW減速機,S68R38Y0.18KW減速機,S68R38Y0.25KW減速機,S68R38Y0.37KW減速機,S68R38Y0.55KW減速機（可配變頻電機，剎車電機，防爆電機，伺服電機，交流電機，直流電機，三相電機，單相電機）。
S68R38減速機配0.12KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S68R38-Y0.12KW | 1194 | 0.12KW | 1.20r/min | 585N.m | 40kg | 7990N | 0.95 |
| S68R38-Y0.12KW | 1045 | 0.12KW | 1.30r/min | 530N.m | 40kg | 8560N | 1.05 |
| S68R38-Y0.12KW | 914 | 0.12KW | 1.50r/min | 455N.m | 40kg | 9180N | 1.25 |
| S68R38-Y0.12KW | 809 | 0.12KW | 1.70r/min | 415N.m | 40kg | 9460N | 1.35 |
| S68R38-Y0.12KW | 712 | 0.12KW | 1.90r/min | 365N.m | 40kg | 9780N | 1.55 |
| S68R38-Y0.12KW | 615 | 0.12KW | 2.20r/min | 305N.m | 40kg | 10100N | 1.85 |
| S68R38-Y0.12KW | 543 | 0.12KW | 2.50r/min | 275N.m | 40kg | 10200N | 2.10 |
| S68R38-Y0.12KW | 469 | 0.12KW | 2.90r/min | 225N.m | 40kg | 10400N | 2.50 |
| S68R38-Y0.12KW | 424 | 0.12KW | 3.30r/min | 200N.m | 40kg | 10500N | 2.80 |
| S68R38-Y0.12KW | 365 | 0.12KW | 3.80r/min | 187N.m | 40kg | 10500N | 3.00 |
S68R38減速機配0.18KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S68R38-Y0.18KW | 712 | 0.18KW | 1.90r/min | 600N.m | 40.5kg | 7860N | 0.95 |
| S68R38-Y0.18KW | 615 | 0.18KW | 2.20r/min | 505N.m | 40.5kg | 8800N | 1.15 |
| S68R38-Y0.18KW | 543 | 0.18KW | 2.40r/min | 450N.m | 40.5kg | 9230N | 1.25 |
| S68R38-Y0.18KW | 469 | 0.18KW | 2.80r/min | 375N.m | 40.5kg | 9720N | 1.50 |
| S68R38-Y0.18KW | 424 | 0.18KW | 3.10r/min | 340N.m | 40.5kg | 9930N | 1.65 |
| S68R38-Y0.18KW | 365 | 0.18KW | 3.60r/min | 305N.m | 40.5kg | 10100N | 1.85 |
S68R38減速機配0.25KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S68R38-Y0.25KW | 543 | 0.25KW | 2.40r/min | 650N.m | 44.5kg | 6280N | 0.85 |
| S68R38-Y0.25KW | 469 | 0.25KW | 2.80r/min | 550N.m | 44.5kg | 8390N | 1.05 |
| S68R38-Y0.25KW | 424 | 0.25KW | 3.10r/min | 495N.m | 44.5kg | 8880N | 1.15 |
| S68R38-Y0.25KW | 365 | 0.25KW | 3.60r/min | 440N.m | 44.5kg | 9320N | 1.30 |
| S68R38-Y0.25KW | 319 | 0.25KW | 4.10r/min | 380N.m | 44.5kg | 9700N | 1.50 |
| S68R38-Y0.25KW | 281 | 0.25KW | 4.60r/min | 335N.m | 44.5kg | 9960N | 1.70 |
S68R38減速機配0.37KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S68R38-Y0.37KW | 365 | 0.37KW | 3.80r/min | 620N.m | 45kg | 7560N | 0.90 |
| S68R38-Y0.37KW | 319 | 0.37KW | 4.30r/min | 540N.m | 45kg | 8450N | 1.05 |
| S68R38-Y0.37KW | 281 | 0.37KW | 4.90r/min | 475N.m | 45kg | 9030N | 1.20 |
| S68R38-Y0.37KW | 246 | 0.37KW | 5.60r/min | 430N.m | 45kg | 9380N | 1.30 |
S68R38減速機配0.55KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S68R38-Y0.55KW | 246 | 0.55KW | 5.60r/min | 645N.m | 49.5kg | 6520N | 0.90 |
| S68R38-Y0.55KW | 221 | 0.55KW | 6.20r/min | 580N.m | 49.5kg | 8080N | 1.00 |
| S68R38-Y0.55KW | 198 | 0.55KW | 7.00r/min | 525N.m | 49.5kg | 8590N | 1.10 |
| S68R38-Y0.55KW | 168 | 0.55KW | 8.20r/min | 450N.m | 49.5kg | 9220N | 1.25 |
S68R38減速器減速比：168比蝸輪蝸桿減速機,198比減速器,221比減速器,246比減速器,281比減速器,319比減速器,365比減速器,424比減速器,469比減速器,543比減速器,615比減速器,712比減速器,809比減速器,914比減速器,1045比減速器,1194比減速器。
S68R38減速機電機安裝尺寸：輸出軸+鍵Φ38（可定做），高236*寬250（帶輸出軸）*長398
S68R38減速電機輸出轉數：1.2轉減速電機,1.3轉減速電機,1.5轉減速電機,1.7轉減速電機,1.9轉自鎖減速機,2.2轉減速電機,2.4轉減速電機,2.5轉減速電機,2.8轉減速電機,2.9轉減速電機,3.1轉減速電機,3.3轉減速電機,3.6轉減速電機,3.8轉減速電機,4.1轉減速電機,4.3轉減速電機,4.6轉減速電機,4.9轉減速電機,5.6轉減速電機,6.2轉減速電機,7轉減速電機,8.2轉減速電機。
S68R38減速箱電機輸出扭矩：187N.m減速箱,200N.m減速箱,225N.m減速箱,275N.m減速箱,305N.m減速箱,335N.m減速箱,340N.m減速箱,365N.m減速箱,375N.m減速箱,380N.m減速箱,415N.m減速箱,430N.m減速箱,440N.m減速箱,450N.m減速箱,455N.m減速箱,475N.m減速箱,495N.m減速箱,505N.m減速箱,525N.m減速箱,530N.m減速箱,540N.m減速箱,550N.m減速箱,580N.m減速箱,585N.m減速箱,600N.m減速箱,620N.m減速箱,645N.m減速箱,650N.m減速箱。
S68R38減速機電機各種輸出實物圖：
S68R38減速馬達型號：
SHZ67R37DM63L4,SHZ67R37DM63M4,SHZ67R37DM63MS4,SHZ67R37DM63S4,SHZ67R37DM71D4,SHZ67R37DM71M4,SHZ67R37DM71MS4,SHZ67R37DM71S4,SHZ67R37DM80K4,SHZ67R37DM80M4,SHZ67R37DM80MK4,SHZ67R37DM80N4,SHZ67R37DM80S4,SHZ67R37DR63L4,SHZ67R37DR63M4,SHZ67R37DR63MS4,SHZ67R37DR63S4,SHZ67R37DR71D4,SHZ67R37DR71M4,SHZ67R37DR71MS4,SHZ67R37DR71S4,SHZ67R37DR80K4,SHZ67R37DR80M4,SHZ67R37DR80MK4,SHZ67R37DR80N4,SHZ67R37DR80S4,SHZ67R37DRE63L4,SHZ67R37DRE63M4,SHZ67R37DRE63MS4,SHZ67R37DRE63S4,SHZ67R37DRE71D4,SHZ67R37DRE71M4,SHZ67R37DRE71MS4,SHZ67R37DRE71S4,SHZ67R37DRE80K4,SHZ67R37DRE80M4,SHZ67R37DRE80MK4,SHZ67R37DRE80N4,SHZ67R37DRE80S4,SHZ67R37DRN63L4,SHZ67R37DRN63M4,SHZ67R37DRN63MS4,SHZ67R37DRN63S4,SHZ67R37DRN71D4,SHZ67R37DRN71M4,SHZ67R37DRN71MS4,SHZ67R37DRN71S4,SHZ67R37DRN80K4,SHZ67R37DRN80M4,SHZ67R37DRN80MK4,SHZ67R37DRN80N4,SHZ67R37DRN80S4,SHZ67R37DRS63L4,SHZ67R37DRS63M4,SHZ67R37DRS63MS4,SHZ67R37DRS63S4,SHZ67R37DRS71D4,SHZ67R37DRS71M4,SHZ67R37DRS71MS4,SHZ67R37DRS71S4,SHZ67R37DRS80K4,SHZ67R37DRS80M4,SHZ67R37DRS80MK4,SHZ67R37DRS80N4,SHZ67R37DRS80S4,SHZ67R37DT63L4,SHZ67R37DT63M4,SHZ67R37DT63MS4,SHZ67R37DT63S4,SHZ67R37DT71D4,SHZ67R37DT71M4,SHZ67R37DT71MS4,SHZ67R37DT71S4,SHZ67R37DT80K4,SHZ67R37DT80M4,SHZ67R37DT80MK4,SHZ67R37DT80N4,SHZ67R37DT80S4,SHZ67R37DV63L4,SHZ67R37DV63M4,SHZ67R37DV63MS4,SHZ67R37DV63S4,SHZ67R37DV71D4,SHZ67R37DV71M4,SHZ67R37DV71MS4,SHZ67R37DV71S4,SHZ67R37DV80K4,SHZ67R37DV80M4,SHZ67R37DV80MK4,SHZ67R37DV80N4,SHZ67R37DV80S4,SHZ67R37DVE63L4,SHZ67R37DVE63M4,SHZ67R37DVE63MS4,SHZ67R37DVE63S4,SHZ67R37DVE71D4,SHZ67R37DVE71M4,SHZ67R37DVE71MS4,SHZ67R37DVE71S4,SHZ67R37DVE80K4,SHZ67R37DVE80M4,SHZ67R37DVE80MK4,SHZ67R37DVE80N4,SHZ67R37DVE80S4,SHZ67RF37-Y0.12KW,SHZ67RF37-Y0.18KW,SHZ67RF37-Y0.25KW,SHZ67RF37-Y0.37KW,SHZ67RF37-Y0.55KW,SHZ67RF37-Y63M4,SHZ67RF37-Y71M4,SHZ67RF37-Y80M4,SHZ67RF37-YEJ0.12KW,SHZ67RF37-YEJ0.18KW,SHZ67RF37-YEJ0.25KW,SHZ67RF37-YEJ0.37KW,SHZ67RF37-YEJ0.55KW,SHZ67RF37-YEJ63M4,SHZ67RF37-YEJ71M4,SHZ67RF37-YEJ80M4,SHZ67RF37-YVP0.12KW,SHZ67RF37-YVP0.18KW,SHZ67RF37-YVP0.25KW,SHZ67RF37-YVP0.37KW,SHZ67RF37-YVP0.55KW,SHZ67RF37-YVP63M4,SHZ67RF37-YVP71M4,SHZ67RF37-YVP80M4,SHZ67RF37-YVPEJ0.12KW,SHZ67RF37-YVPEJ0.18KW,SHZ67RF37-YVPEJ0.25KW,SHZ67RF37-YVPEJ0.37KW,SHZ67RF37-YVPEJ0.55KW,SHZ67RF37-YVPEJ63M4,SHZ67RF37-YVPEJ71M4,SHZ67RF37-YVPEJ80M4,SAZ67R37DM63L4,SAZ67R37DM63M4,SAZ67R37DM63MS4,SAZ67R37DM63S4,SAZ67R37DM71D4,SAZ67R37DM71M4,SAZ67R37DM71MS4,SAZ67R37DM71S4,SAZ67R37DM80K4,SAZ67R37DM80M4,SAZ67R37DM80MK4,SAZ67R37DM80N4,SAZ67R37DM80S4,SAZ67R37DR63L4,SAZ67R37DR63M4,SAZ67R37DR63MS4,SAZ67R37DR63S4,SAZ67R37DR71D4,SAZ67R37DR71M4,SAZ67R37DR71MS4,SAZ67R37DR71S4,SAZ67R37DR80K4,SAZ67R37DR80M4,SAZ67R37DR80MK4,SAZ67R37DR80N4,SAZ67R37DR80S4,SAZ67R37DRE63L4,SAZ67R37DRE63M4,SAZ67R37DRE63MS4,SAZ67R37DRE63S4,SAZ67R37DRE71D4,SAZ67R37DRE71M4,SAZ67R37DRE71MS4,SAZ67R37DRE71S4,SAZ67R37DRE80K4,SAZ67R37DRE80M4,SAZ67R37DRE80MK4,SAZ67R37DRE80N4,SAZ67R37DRE80S4,SAZ67R37DRN63L4,SAZ67R37DRN63M4,SAZ67R37DRN63MS4,SAZ67R37DRN63S4,SAZ67R37DRN71D4,SAZ67R37DRN71M4,SAZ67R37DRN71MS4,SAZ67R37DRN71S4,SAZ67R37DRN80K4,SAZ67R37DRN80M4,SAZ67R37DRN80MK4,SAZ67R37DRN80N4,SAZ67R37DRN80S4,SAZ67R37DRS63L4,SAZ67R37DRS63M4,SAZ67R37DRS63MS4,SAZ67R37DRS63S4,SAZ67R37DRS71D4,SAZ67R37DRS71M4,SAZ67R37DRS71MS4,SAZ67R37DRS71S4,SAZ67R37DRS80K4,SAZ67R37DRS80M4,SAZ67R37DRS80MK4,SAZ67R37DRS80N4,SAZ67R37DRS80S4,SAZ67R37DT63L4,SAZ67R37DT63M4,SAZ67R37DT63MS4,SAZ67R37DT63S4,SAZ67R37DT71D4,SAZ67R37DT71M4,SAZ67R37DT71MS4,SAZ67R37DT71S4,SAZ67R37DT80K4,SAZ67R37DT80M4,SAZ67R37DT80MK4,SAZ67R37DT80N4,SAZ67R37DT80S4,SAZ67R37DV63L4,SAZ67R37DV63M4,SAZ67R37DV63MS4,SAZ67R37DV63S4,SAZ67R37DV71D4,SAZ67R37DV71M4,SAZ67R37DV71MS4,SAZ67R37DV71S4,SAZ67R37DV80K4,SAZ67R37DV80M4,SAZ67R37DV80MK4,SAZ67R37DV80N4,SAZ67R37DV80S4,SAZ67R37DVE63L4,SAZ67R37DVE63M4,SAZ67R37DVE63MS4,SAZ67R37DVE63S4,SAZ67R37DVE71D4,SAZ67R37DVE71M4,SAZ67R37DVE71MS4,SAZ67R37DVE71S4,SAZ67R37DVE80K4,SAZ67R37DVE80M4,SAZ67R37DVE80MK4,SAZ67R37DVE80N4,SAZ67R37DVE80S4,SAZ67RF37-Y0.12KW,SAZ67RF37-Y0.18KW,SAZ67RF37-Y0.25KW,SAZ67RF37-Y0.37KW,SAZ67RF37-Y0.55KW,SAZ67RF37-Y63M4,SAZ67RF37-Y71M4,SAZ67RF37-Y80M4,SAZ67RF37-YEJ0.12KW,SAZ67RF37-YEJ0.18KW,SAZ67RF37-YEJ0.25KW,SAZ67RF37-YEJ0.37KW,SAZ67RF37-YEJ0.55KW,SAZ67RF37-YEJ63M4,SAZ67RF37-YEJ71M4,SAZ67RF37-YEJ80M4,SAZ67RF37-YVP0.12KW,SAZ67RF37-YVP0.18KW,SAZ67RF37-YVP0.25KW,SAZ67RF37-YVP0.37KW,SAZ67RF37-YVP0.55KW,SAZ67RF37-YVP63M4,SAZ67RF37-YVP71M4,SAZ67RF37-YVP80M4,SAZ67RF37-YVPEJ0.12KW,SAZ67RF37-YVPEJ0.18KW,SAZ67RF37-YVPEJ0.25KW,SAZ67RF37-YVPEJ0.37KW,SAZ67RF37-YVPEJ0.55KW,SAZ67RF37-YVPEJ63M4,SAZ67RF37-YVPEJ71M4,SAZ67RF37-YVPEJ80M4。
S68R38減速電機生產廠家展示：看廠請聯系微信13827261050，獲取位置，需提前一天預約http://www.dongfangwy.com/product/list-sxiliejiansuji-cn.html
推薦型號：S68減速機
關鍵詞:G系列減速機一體式_S系列斜齒輪蝸輪蝸桿減速機_S系列減速機_減速機配司服電機連接_S型減速機_司服電機減速機_S系列減速機器_司服減速機
S系列減速機型號：S38減速機,S48減速機,S58減速機,S68減速機,S78減速機,S88減速機,S98齒輪減速馬達
S系列自鎖減速機可配變頻電機，剎車電機，防爆電機，伺服電機，交流電機，直流電機，三相電機，單相電機 0.12KW-22KW之間
如需工程師幫選型，請加微信13827261050，留言告知工程師參數要求
標簽: SHZ67R37 SAZ67R37
