S98R58減速機詳細信息
S98R58減速機
訂購熱線：13360667204
S98R58減速機電機功率：S98R58Y0.12KW減速機,S98R58Y0.75KW減速機,S98R58Y1.1KW減速機,S98R58Y1.5KW減速機,S98R58Y2.2KW減速機,S98R58Y3KW減速機,S98R58Y4KW減速機（可配變頻電機，剎車電機，防爆電機，伺服電機，交流電機，直流電機，三相電機，單相電機）。
S98R58減速機配0.12KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S98R58-Y0.12KW | 11267 | 0.12KW | 0.12r/min | 4740N.m | 193.5kg | 25100N | 0.90 |
| S98R58-Y0.12KW | 10078 | 0.12KW | 0.14r/min | 4330N.m | 193.5kg | 32500N | 0.95 |
| S98R58-Y0.12KW | 8608 | 0.12KW | 0.16r/min | 3590N.m | 193.5kg | 34000N | 1.15 |
| S98R58-Y0.12KW | 7554 | 0.12KW | 0.18r/min | 3180N.m | 193.5kg | 34700N | 1.30 |
S98R58減速機配0.75KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S98R58-Y0.75KW | 1223 | 0.75KW | 1.20r/min | 4710N.m | 204kg | 23400N | 0.90 |
| S98R58-Y0.75KW | 1070 | 0.75KW | 1.30r/min | 4130N.m | 204kg | 32200N | 1.00 |
| S98R58-Y0.75KW | 928 | 0.75KW | 1.60r/min | 3550N.m | 204kg | 34000N | 1.20 |
| S98R58-Y0.75KW | 824 | 0.75KW | 1.70r/min | 3140N.m | 204kg | 34700N | 1.35 |
| S98R58-Y0.75KW | 714 | 0.75KW | 2.00r/min | 2240N.m | 204kg | 35900N | 1.85 |
| S98R58-Y0.75KW | 626 | 0.75KW | 2.30r/min | 2380N.m | 204kg | 35800N | 1.75 |
| S98R58-Y0.75KW | 538 | 0.75KW | 2.70r/min | 2040N.m | 204kg | 36100N | 2.00 |
| S98R58-Y0.75KW | 484 | 0.75KW | 3.00r/min | 1850N.m | 204kg | 36300N | 2.30 |
S98R58減速機配1.1KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S98R58-Y1.1KW | 824 | 1.1KW | 1.70r/min | 4700N.m | 208kg | 23500N | 0.90 |
| S98R58-Y1.1KW | 714 | 1.1KW | 2.00r/min | 3360N.m | 208kg | 34400N | 1.25 |
| S98R58-Y1.1KW | 626 | 1.1KW | 2.30r/min | 3570N.m | 208kg | 34000N | 1.15 |
| S98R58-Y1.1KW | 538 | 1.1KW | 2.60r/min | 3070N.m | 208kg | 34800N | 1.35 |
| S98R58-Y1.1KW | 484 | 1.1KW | 2.90r/min | 2780N.m | 208kg | 35300N | 1.50 |
| S98R58-Y1.1KW | 420 | 1.1KW | 3.40r/min | 2410N.m | 208kg | 35700N | 1.75 |
S98R58減速機配1.5KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S98R58-Y1.5KW | 714 | 1.5KW | 2.00r/min | 4580N.m | 211kg | 29300N | 0.90 |
| S98R58-Y1.5KW | 626 | 1.5KW | 2.30r/min | 4870N.m | 211kg | 19700N | 0.85 |
| S98R58-Y1.5KW | 538 | 1.5KW | 2.70r/min | 4200N.m | 211kg | 31300N | 1.00 |
| S98R58-Y1.5KW | 484 | 1.5KW | 3.00r/min | 3790N.m | 211kg | 33600N | 1.10 |
| S98R58-Y1.5KW | 420 | 1.5KW | 3.40r/min | 3300N.m | 211kg | 34500N | 1.25 |
| S98R58-Y1.5KW | 376 | 1.5KW | 3.80r/min | 2980N.m | 211kg | 35000N | 1.40 |
| S98R58-Y1.5KW | 327 | 1.5KW | 4.40r/min | 2610N.m | 211kg | 35500N | 1.60 |
S98R58減速機配2.2KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S98R58-Y2.2KW | 420 | 2.2KW | 3.40r/min | 4890N.m | 220kg | 19000N | 0.85 |
| S98R58-Y2.2KW | 376 | 2.2KW | 3.80r/min | 4410N.m | 220kg | 28300N | 0.95 |
| S98R58-Y2.2KW | 327 | 2.2KW | 4.40r/min | 3870N.m | 220kg | 33400N | 1.10 |
| S98R58-Y2.2KW | 287 | 2.2KW | 5.00r/min | 3420N.m | 220kg | 34300N | 1.25 |
| S98R58-Y2.2KW | 252 | 2.2KW | 5.70r/min | 2990N.m | 220kg | 35000N | 1.40 |
S98R58減速機配3KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S98R58-Y3KW | 287 | 3KW | 5.10r/min | 4580N.m | 223kg | 25700N | 0.90 |
| S98R58-Y3KW | 252 | 3KW | 5.80r/min | 4020N.m | 223kg | 33100N | 1.05 |
| S98R58-Y3KW | 219 | 3KW | 6.60r/min | 3510N.m | 223kg | 34100N | 1.20 |
| S98R58-Y3KW | 205 | 3KW | 7.10r/min | 3300N.m | 223kg | 34500N | 1.25 |
S98R58減速機配4KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S98R58-Y4KW | 219 | 4KW | 6.70r/min | 4690N.m | 234kg | 24100N | 0.90 |
| S98R58-Y4KW | 205 | 4KW | 7.10r/min | 4410N.m | 234kg | 28500N | 0.95 |
S98R58減速器減速比：11267比減速器,10078比蝸輪蝸桿減速機,8608比減速器,7554比減速器,1223比減速器,1070比減速器,928比減速器,824比減速器,714比減速器,626比減速器,538比減速器,484比減速器,420比減速器,376比減速器,327比減速器,287比減速器,252比減速器,219比減速器,205比減速器。
S98R58減速機電機安裝尺寸：輸出軸+鍵Φ74.5（可定做），高455*寬450（帶輸出軸）*長607
S98R58減速電機輸出轉數：0.12轉減速電機,0.14轉減速電機,0.16轉減速電機,0.18轉減速電機,1.2轉減速電機,1.3轉減速電機,1.6轉減速電機,1.7轉減速電機,2轉減速電機,2.3轉減速電機,2.6轉減速電機,2.7轉減速電機,2.9轉減速電機,3轉減速電機,3.4轉減速電機,3.8轉減速電機,4.4轉減速電機,5轉減速電機,5.7轉自鎖減速機,5.1轉減速電機,5.8轉減速電機,6.6轉減速電機,6.7轉減速電機,7.1轉減速電機。
S98R58減速箱電機輸出扭矩：4740N.m減速箱,4330N.m減速箱,3590N.m減速箱,3180N.m減速箱,4710N.m減速箱,4130N.m減速箱,3550N.m減速箱,3140N.m減速箱,2240N.m減速箱,2380N.m減速箱,2040N.m減速箱,1850N.m減速箱,4700N.m減速箱,3360N.m減速箱,3570N.m減速箱,3070N.m減速箱,2780N.m減速箱,2410N.m減速箱,4580N.m減速箱,4870N.m減速箱,4200N.m減速箱,3790N.m減速箱,3300N.m減速箱,2980N.m減速箱,26104980N.m減速箱,4410N.m減速箱,3870N.m減速箱,3420N.m減速箱,2990N.m減速箱,4580N.m減速箱,4020N.m減速箱,3510N.m減速箱,3300N.m減速箱,4690N.m減速箱,4410N.m減速箱。
S98R58減速機電機各種輸出實物圖：
S98R58減速馬達型號：
SHZ97R57DM100LC4,SHZ97R57DM100LS4,SHZ97R57DM100M4,SHZ97R57DM100S4,SHZ97R57DM112M4,SHZ97R57DM63L4,SHZ97R57DM63M4,SHZ97R57DM63MS4,SHZ97R57DM63S4,SHZ97R57DM71D4,SHZ97R57DM71MS4,SHZ97R57DM71S4,SHZ97R57DM80K4,SHZ97R57DM80M4,SHZ97R57DM80MK4,SHZ97R57DM80N4,SHZ97R57DM80S4,SHZ97R57DM90L4,SHZ97R57DM90M4,SHZ97R57DM90S4,SHZ97R57DR100LC4,SHZ97R57DR100LS4,SHZ97R57DR100M4,SHZ97R57DR100S4,SHZ97R57DR112M4,SHZ97R57DR63L4,SHZ97R57DR63M4,SHZ97R57DR63MS4,SHZ97R57DR63S4,SHZ97R57DR71D4,SHZ97R57DR71MS4,SHZ97R57DR71S4,SHZ97R57DR80K4,SHZ97R57DR80M4,SHZ97R57DR80MK4,SHZ97R57DR80N4,SHZ97R57DR80S4,SHZ97R57DR90L4,SHZ97R57DR90M4,SHZ97R57DR90S4,SHZ97R57DRE100LC4,SHZ97R57DRE100LS4,SHZ97R57DRE100M4,SHZ97R57DRE100S4,SHZ97R57DRE112M4,SHZ97R57DRE63L4,SHZ97R57DRE63M4,SHZ97R57DRE63MS4,SHZ97R57DRE63S4,SHZ97R57DRE71D4,SHZ97R57DRE71MS4,SHZ97R57DRE71S4,SHZ97R57DRE80K4,SHZ97R57DRE80M4,SHZ97R57DRE80MK4,SHZ97R57DRE80N4,SHZ97R57DRE80S4,SHZ97R57DRE90L4,SHZ97R57DRE90M4,SHZ97R57DRE90S4,SHZ97R57DRN100LC4,SHZ97R57DRN100LS4,SHZ97R57DRN100M4,SHZ97R57DRN100S4,SHZ97R57DRN112M4,SHZ97R57DRN63L4,SHZ97R57DRN63M4,SHZ97R57DRN63MS4,SHZ97R57DRN63S4,SHZ97R57DRN71D4,SHZ97R57DRN71MS4,SHZ97R57DRN71S4,SHZ97R57DRN80K4,SHZ97R57DRN80M4,SHZ97R57DRN80MK4,SHZ97R57DRN80N4,SHZ97R57DRN80S4,SHZ97R57DRN90L4,SHZ97R57DRN90M4,SHZ97R57DRN90S4,SHZ97R57DRS100LC4,SHZ97R57DRS100LS4,SHZ97R57DRS100M4,SHZ97R57DRS100S4,SHZ97R57DRS112M4,SHZ97R57DRS63L4,SHZ97R57DRS63M4,SHZ97R57DRS63MS4,SHZ97R57DRS63S4,SHZ97R57DRS71D4,SHZ97R57DRS71MS4,SHZ97R57DRS71S4,SHZ97R57DRS80K4,SHZ97R57DRS80M4,SHZ97R57DRS80MK4,SHZ97R57DRS80N4,SHZ97R57DRS80S4,SHZ97R57DRS90L4,SHZ97R57DRS90M4,SHZ97R57DRS90S4,SHZ97R57DT100LC4,SHZ97R57DT100LS4,SHZ97R57DT100M4,SHZ97R57DT100S4,SHZ97R57DT112M4,SHZ97R57DT63L4,SHZ97R57DT63M4,SHZ97R57DT63MS4,SHZ97R57DT63S4,SHZ97R57DT71D4,SHZ97R57DT71MS4,SHZ97R57DT71S4,SHZ97R57DT80K4,SHZ97R57DT80M4,SHZ97R57DT80MK4,SHZ97R57DT80N4,SHZ97R57DT80S4,SHZ97R57DT90L4,SHZ97R57DT90M4,SHZ97R57DT90S4,SHZ97R57DV100LC4,SHZ97R57DV100LS4,SHZ97R57DV100M4,SHZ97R57DV100S4,SHZ97R57DV112M4,SHZ97R57DV63L4,SHZ97R57DV63M4,SHZ97R57DV63MS4,SHZ97R57DV63S4,SHZ97R57DV71D4,SHZ97R57DV71MS4,SHZ97R57DV71S4,SHZ97R57DV80K4,SHZ97R57DV80M4,SHZ97R57DV80MK4,SHZ97R57DV80N4,SHZ97R57DV80S4,SHZ97R57DV90L4,SHZ97R57DV90M4,SHZ97R57DV90S4,SHZ97R57DVE100LC4,SHZ97R57DVE100LS4,SHZ97R57DVE100M4,SHZ97R57DVE100S4,SHZ97R57DVE112M4,SHZ97R57DVE63L4,SHZ97R57DVE63M4,SHZ97R57DVE63MS4,SHZ97R57DVE63S4,SHZ97R57DVE71D4,SHZ97R57DVE71MS4,SHZ97R57DVE71S4,SHZ97R57DVE80K4,SHZ97R57DVE80M4,SHZ97R57DVE80MK4,SHZ97R57DVE80N4,SHZ97R57DVE80S4,SHZ97R57DVE90L4,SHZ97R57DVE90M4,SHZ97R57DVE90S4,SHZ97RF57-Y0.12KW,SHZ97RF57-Y0.18KW,SHZ97RF57-Y0.75KW,SHZ97RF57-Y1.1KW,SHZ97RF57-Y1.5KW,SHZ97RF57-Y100M4,SHZ97RF57-Y112M4,SHZ97RF57-Y2.2KW,SHZ97RF57-Y3KW,SHZ97RF57-Y4KW,SHZ97RF57-Y63M4,SHZ97RF57-Y80M4,SHZ97RF57-Y90M4,SHZ97RF57-YEJ0.12KW,SHZ97RF57-YEJ0.18KW,SHZ97RF57-YEJ0.75KW,SHZ97RF57-YEJ1.1KW,SHZ97RF57-YEJ1.5KW,SHZ97RF57-YEJ100L4,SHZ97RF57-YEJ112M4,SHZ97RF57-YEJ2.2KW,SHZ97RF57-YEJ3KW,SHZ97RF57-YEJ4KW,SHZ97RF57-YEJ63M4,SHZ97RF57-YEJ80M4,SHZ97RF57-YEJ90S4,SHZ97RF57-YVP0.12KW,SHZ97RF57-YVP0.18KW,SHZ97RF57-YVP0.75KW,SHZ97RF57-YVP1.1KW,SHZ97RF57-YVP1.5KW,SHZ97RF57-YVP100L4,SHZ97RF57-YVP112M4,SHZ97RF57-YVP2.2KW,SHZ97RF57-YVP3KW,SHZ97RF57-YVP4KW,SHZ97RF57-YVP63M4,SHZ97RF57-YVP80M4,SHZ97RF57-YVP90S4,SHZ97RF57-YVPEJ0.12KW,SHZ97RF57-YVPEJ0.18KW,SHZ97RF57-YVPEJ0.75KW,SHZ97RF57-YVPEJ1.1KW,SHZ97RF57-YVPEJ1.5KW,SHZ97RF57-YVPEJ100L4,SHZ97RF57-YVPEJ112M4,SHZ97RF57-YVPEJ2.2KW,SHZ97RF57-YVPEJ3KW,SHZ97RF57-YVPEJ4KW,SHZ97RF57-YVPEJ63M4,SHZ97RF57-YVPEJ80M4,SHZ97RF57-YVPEJ90S4,SAZ97R57DM100LC4,SAZ97R57DM100LS4,SAZ97R57DM100M4,SAZ97R57DM100S4,SAZ97R57DM112M4,SAZ97R57DM63L4,SAZ97R57DM63M4,SAZ97R57DM63MS4,SAZ97R57DM63S4,SAZ97R57DM71D4,SAZ97R57DM71MS4,SAZ97R57DM71S4,SAZ97R57DM80K4,SAZ97R57DM80M4,SAZ97R57DM80MK4,SAZ97R57DM80N4,SAZ97R57DM80S4,SAZ97R57DM90L4,SAZ97R57DM90M4,SAZ97R57DM90S4,SAZ97R57DR100LC4,SAZ97R57DR100LS4,SAZ97R57DR100M4,SAZ97R57DR100S4,SAZ97R57DR112M4,SAZ97R57DR63L4,SAZ97R57DR63M4,SAZ97R57DR63MS4,SAZ97R57DR63S4,SAZ97R57DR71D4,SAZ97R57DR71MS4,SAZ97R57DR71S4,SAZ97R57DR80K4,SAZ97R57DR80M4,SAZ97R57DR80MK4,SAZ97R57DR80N4,SAZ97R57DR80S4,SAZ97R57DR90L4,SAZ97R57DR90M4,SAZ97R57DR90S4,SAZ97R57DRE100LC4,SAZ97R57DRE100LS4,SAZ97R57DRE100M4,SAZ97R57DRE100S4,SAZ97R57DRE112M4,SAZ97R57DRE63L4,SAZ97R57DRE63M4,SAZ97R57DRE63MS4,SAZ97R57DRE63S4,SAZ97R57DRE71D4,SAZ97R57DRE71MS4,SAZ97R57DRE71S4,SAZ97R57DRE80K4,SAZ97R57DRE80M4,SAZ97R57DRE80MK4,SAZ97R57DRE80N4,SAZ97R57DRE80S4,SAZ97R57DRE90L4,SAZ97R57DRE90M4,SAZ97R57DRE90S4,SAZ97R57DRN100LC4,SAZ97R57DRN100LS4,SAZ97R57DRN100M4,SAZ97R57DRN100S4,SAZ97R57DRN112M4,SAZ97R57DRN63L4,SAZ97R57DRN63M4,SAZ97R57DRN63MS4,SAZ97R57DRN63S4,SAZ97R57DRN71D4,SAZ97R57DRN71MS4,SAZ97R57DRN71S4,SAZ97R57DRN80K4,SAZ97R57DRN80M4,SAZ97R57DRN80MK4,SAZ97R57DRN80N4,SAZ97R57DRN80S4,SAZ97R57DRN90L4,SAZ97R57DRN90M4,SAZ97R57DRN90S4,SAZ97R57DRS100LC4,SAZ97R57DRS100LS4,SAZ97R57DRS100M4,SAZ97R57DRS100S4,SAZ97R57DRS112M4,SAZ97R57DRS63L4,SAZ97R57DRS63M4,SAZ97R57DRS63MS4,SAZ97R57DRS63S4,SAZ97R57DRS71D4,SAZ97R57DRS71MS4,SAZ97R57DRS71S4,SAZ97R57DRS80K4,SAZ97R57DRS80M4,SAZ97R57DRS80MK4,SAZ97R57DRS80N4,SAZ97R57DRS80S4,SAZ97R57DRS90L4,SAZ97R57DRS90M4,SAZ97R57DRS90S4,SAZ97R57DT100LC4,SAZ97R57DT100LS4,SAZ97R57DT100M4,SAZ97R57DT100S4,SAZ97R57DT112M4,SAZ97R57DT63L4,SAZ97R57DT63M4,SAZ97R57DT63MS4,SAZ97R57DT63S4,SAZ97R57DT71D4,SAZ97R57DT71MS4,SAZ97R57DT71S4,SAZ97R57DT80K4,SAZ97R57DT80M4,SAZ97R57DT80MK4,SAZ97R57DT80N4,SAZ97R57DT80S4,SAZ97R57DT90L4,SAZ97R57DT90M4,SAZ97R57DT90S4,SAZ97R57DV100LC4,SAZ97R57DV100LS4,SAZ97R57DV100M4,SAZ97R57DV100S4,SAZ97R57DV112M4,SAZ97R57DV63L4,SAZ97R57DV63M4,SAZ97R57DV63MS4,SAZ97R57DV63S4,SAZ97R57DV71D4,SAZ97R57DV71MS4,SAZ97R57DV71S4,SAZ97R57DV80K4,SAZ97R57DV80M4,SAZ97R57DV80MK4,SAZ97R57DV80N4,SAZ97R57DV80S4,SAZ97R57DV90L4,SAZ97R57DV90M4,SAZ97R57DV90S4,SAZ97R57DVE100LC4,SAZ97R57DVE100LS4,SAZ97R57DVE100M4,SAZ97R57DVE100S4,SAZ97R57DVE112M4,SAZ97R57DVE63L4,SAZ97R57DVE63M4,SAZ97R57DVE63MS4,SAZ97R57DVE63S4,SAZ97R57DVE71D4,SAZ97R57DVE71MS4,SAZ97R57DVE71S4,SAZ97R57DVE80K4,SAZ97R57DVE80M4,SAZ97R57DVE80MK4,SAZ97R57DVE80N4,SAZ97R57DVE80S4,SAZ97R57DVE90L4,SAZ97R57DVE90M4,SAZ97R57DVE90S4,SAZ97RF57-Y0.12KW,SAZ97RF57-Y0.18KW,SAZ97RF57-Y0.75KW,SAZ97RF57-Y1.1KW,SAZ97RF57-Y1.5KW,SAZ97RF57-Y100M4,SAZ97RF57-Y112M4,SAZ97RF57-Y2.2KW,SAZ97RF57-Y3KW,SAZ97RF57-Y4KW,SAZ97RF57-Y63M4,SAZ97RF57-Y80M4,SAZ97RF57-Y90M4,SAZ97RF57-YEJ0.12KW,SAZ97RF57-YEJ0.18KW,SAZ97RF57-YEJ0.75KW,SAZ97RF57-YEJ1.1KW,SAZ97RF57-YEJ1.5KW,SAZ97RF57-YEJ100L4,SAZ97RF57-YEJ112M4,SAZ97RF57-YEJ2.2KW,SAZ97RF57-YEJ3KW,SAZ97RF57-YEJ4KW,SAZ97RF57-YEJ63M4,SAZ97RF57-YEJ80M4,SAZ97RF57-YEJ90S4,SAZ97RF57-YVP0.12KW,SAZ97RF57-YVP0.18KW,SAZ97RF57-YVP0.75KW,SAZ97RF57-YVP1.1KW,SAZ97RF57-YVP1.5KW,SAZ97RF57-YVP100L4,SAZ97RF57-YVP112M4,SAZ97RF57-YVP2.2KW,SAZ97RF57-YVP3KW,SAZ97RF57-YVP4KW,SAZ97RF57-YVP63M4,SAZ97RF57-YVP80M4,SAZ97RF57-YVP90S4,SAZ97RF57-YVPEJ0.12KW,SAZ97RF57-YVPEJ0.18KW,SAZ97RF57-YVPEJ0.75KW,SAZ97RF57-YVPEJ1.1KW,SAZ97RF57-YVPEJ1.5KW,SAZ97RF57-YVPEJ100L4,SAZ97RF57-YVPEJ112M4,SAZ97RF57-YVPEJ2.2KW,SAZ97RF57-YVPEJ3KW,SAZ97RF57-YVPEJ4KW,SAZ97RF57-YVPEJ63M4,SAZ97RF57-YVPEJ80M4,SAZ97RF57-YVPEJ90S4。
S98R58減速電機生產廠家展示：看廠請聯系微信13827261050，獲取位置，需提前一天預約http://www.dongfangwy.com/product/list-sxiliejiansuji-cn.html
推薦型號：S98減速機
關鍵詞:G系列減速機一體式_S系列斜齒輪蝸輪蝸桿減速機_S系列減速機_減速機配司服電機連接_S型減速機_司服電機減速機_S系列減速機器_司服減速機
S系列減速機型號：S38減速機,S48減速機,S58減速機,S68減速機,S78減速機,S88減速機,S98齒輪減速馬達
S系列自鎖減速機可配變頻電機，剎車電機，防爆電機，伺服電機，交流電機，直流電機，三相電機，單相電機 0.12KW-22KW之間
如需工程師幫選型，請加微信13827261050，留言告知工程師參數要求
